Red Pitaya is an open source project developed around a reconfigurable measurement instrument in size of a credit card. It can replace many expensive laboratory measurement and control instruments.
Featured Product: Xilinx Zynq-7000 (Z-7015, Z-7030) System on Module
Trenz Electronic TE0715s are industrial-grade SoC modules integrating a Xilinx Zynq-7000 SoM with 4 MGT Links, a gigabit Ethernet transceiver, 1 gigabyte DDR3 SDRAM with 32-bit width, 32 megabyte Flash memory for conﬁguration and operation, 4 transceivers, a USB ULPI transceiver, and powerful switch-mode power supplies for all on-board voltages.
A large number of conﬁgurable I/Os is provided via rugged high-speed stacking strips. All modules in 4 x 5 cm form factor are mechanically compatible.
All this on a tiny footprint, smaller than a credit card, at the most competitive price.
- Xilinx Zynq-7000 (Z-7015, Z-7030) SoM supported by the free Xilinx Vivado WebPACK tool
- Rugged for shock and high vibration
- 2x ARM Cortex-A9
- 10/100/1000 tri-speed gigabit Ethernet transceiver (PHY) with SGMII
- 32-Bit-wide 1 GByte DDR3 SDRAM
Assembly options for cost or performance optimization available upon request.
